Cabinet Color |
|
Black |
| |
Panel Type |
|
IPS |
| |
Panel Size |
|
27.0" / 68.5 cm |
| |
Native Resolution |
|
2560 x 1440 |
| |
Active Display Size (H × V) |
|
596.7 x 335.7 mm |
| |
Pixel Pitch |
|
0.233 × 0.233 mm |
| |
Display Colors |
|
1.07 billion colors,
10-bit display (from a palette of 278 trillion, 16-bit LUT) |
| |
Viewing Angles (H, V) |
|
178°, 178° |
| |
Brightness (Typical) |
|
400 cd/m2 (maximum) |
| |
Contrast Ratio (Typical) |
|
1600:1 |
| |
Response Time (Typical) |
|
Gray-to-gray: 19 ms |
| |
Wide Gamut Coverage (typical) |
|
Adobe RGB: 99%, DCI-P3: 98% |
| |
Video Input Terminals |
|
USB Type-C (DisplayPort Alt Mode, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3) |
| |
Digital Scanning Frequency (H, V) |
|
USB Type-C, DisplayPort: 26 - 89 kHz / 23 - 61 Hz
HDMI: 15 - 89 kHz / 23 - 61 Hz |
| |
USB |
|
|
| |
Upstream |
|
USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 92 W max.), USB 3.1 Gen 1: Type-B |
| |
Downstream |
|
USB 3.1 Gen 1: Type-A x 2
USB 2.0: Type-A x 2 |
| |
Function |
|
2 ports for monitor control
3-port USB hub |
| |
USB LAN Adapter |
|
RJ-45 (1000BASE-T) |
| |
Power |
|
|
| |
Power Requirements |
|
AC 100 - 240 V, 50 / 60 Hz |
| |
Maximum Power Consumption |
|
187 W |
| |
Typical Power Consumption |
|
17 W |
| |
Power Save Mode |
|
Less than 0.5 W |
| |
Built-in Calibration Sensor |
|
Yes |
| |
Features & Functions |
|
|
| |
Brightness Stabilization |
|
Yes |
| |
Preset Modes |
|
User, BT.2020, BT.709, DCI-P3, PQ_DCI-P3, HLG_BT.2100, AdobeRGB, sRGB, Calibration (CAL), SYNC_SIGNAL |
| |
HDR Gamma |
|
HLG, PQ curve |
| |
Digital Uniformity Equalizer |
|
Yes |
| |
OSD Languages |
|
English, German, French, Spanish, Italian, Swedish, Simplified Chinese, Traditional Chinese, Japanese |
| |
Others |
|
Color Adjustment, PQ Option, HLG Option, SelfCalibration, Input Color Format, YUV Color Matrix, Input Range, I/P Conversion, Picture Expansion, BT.709 Gamut warning, Luminance Warning, Marker, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock, DUE Priority, Ethernet |
| |
Physical Specifications |
|
|
| |
Dimensions (Landscape, W x H x D) |
|
638 x 415.9 - 570.9 x 245 mm |
| |
Dimensions (Landscape with Hood, W x H x D) |
|
648 x 420.9 - 575.9 x 346 mm |
| |
Net Weight |
|
9.4 kg |
| |
Net Weight (With Hood) |
|
9.8 kg |
| |
Height Adjustment Range |
|
155 mm |
| |
Tilt |
|
35° Up, 5° Down |
| |
Swivel |
|
344° |
| |
Pivot |
|
90° |
| |
Hole Spacing (VESA Standard) |
|
100 x 100 mm |
| |
Certifications & Standards
(Please contact EIZO for the latest information.) |
|
CB, CE, UKCA, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics, TUV/Color Accuracy (Quick Stability), FograCert Softproofing System (class A) |
| |
Supplied Accessories |
|
AC power cord, USB Type-C (2 m), HDMI (2 m), USB cable USB Type-A - USB Type-B cable (2 m), Setup guide, Factory Report, ScreenCleaner, Monitor hood, Warranty card |
| |
Warranty |
|
Five Years 1 2 |
