硬體規格 | |
---|---|
連接介面 | 5 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX |
網路連接線 | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
風扇數量 | Fanless |
外接電源供應器 | External Power Adapter(Output: 48VDC / 1.25A) |
PoE連接埠(RJ45) | Standard: 802.3 af compliant PoE Ports: Port1- Port4 Power Supply: 56W |
背板頻寬 | 10Gbps |
MAC位址表 | 2K |
尺寸大小(長 x 寬 x 高) | 3.9 x 3.9 x 1.0 in. (99.8 x 98 x 25 mm) |
最大功耗 | 3.95W(220/50Hz. no PD connected) 64.44W(220/50Hz. with 56W PD connected) |
最大散熱量 | 13.48BTU/h(no PD connected) 219.87BTU/h(with 56W PD connected) |
軟體規格 | |
進階功能 | Compatible With IEEE 802.3af Compliant PDs Priority Function Mac Address Auto-Learning And Auto-Aging IEEE 802.3x Flow Control 802.1p/DSCP QoS IGMP Snooping |
傳輸模式 | Store-And-Forward |
其他規格 | |
認證 | FCC, CE, RoHS |
包裝內容 | TL-SG1005P, Power Adapter, Installation Guide |
消耗量 | 4.26 watts (max. no PD connected) 63.31 watts (max. with 56w PD connected) |
環境 | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~90%RH non-condensing |
