產品特點
- 2MP High Definition and 24h Full-Color
- Human & Vehicle Classification
- Smart Detection
- LightPro Night Vision
- Built-In Microphone
- Smart Video Enhancement Technology
- IP67 Waterproof and IK10 Vandal-Proof
- H.265+ Compression Technology
產品規格
| CAMERA |
| Image Sensor |
1/3” Progressive Scan CMOS |
| Shutter Speed |
1/3 to 1/10000 s |
| Slow Shutter |
Yes |
| Minimum Illumination |
0.2 Lux; 0 Lux with IR/White light |
| Day/Night Mechanism |
IR Cut Filter |
| Day/Night Switch |
Unified/ Scheduled/ Auto |
| LENS |
| Type |
Fixed Focal Lens |
| Focal Length |
2.8 mm / 4 mm |
| Aperture |
F2.0 |
| FOV |
• 2.8 mm:
Horizontal FOV: 98.8°, Vertical FOV: 53.5°, Diagonal FOV: 117°
• 4 mm:
Horizontal : 75.2°, Vertical: 40.8°, Diagonal: 88.3° |
| Lens Mount |
M12 |
| DORI Distance |
• 2.8 mm
Detect: 153 ft (47 m)
Observe: 64 ft (19 m)
Recognize: 31 ft (9 m)
Identify: 15 ft (5 m)
• 4 mm
Detect: 194 ft (59 m)
Observe: 81 ft (25 m)
Recognize: 39 ft (12 m)
Identify: 19 ft (6 m) |
| Angle Adjustment (Manual) |
| Range |
Pan: 0° to 353.5°, Tilt: 0° to 75°, Rotate: 0° to 355° |
| ILLUMINATOR |
| Illuminator On/Off Control |
Auto/Scheduled/Always on/Always off |
| Integrated Infrared-White LED |
• Quantity: 2
• IR Range: 98 ft (30 m)*3
• White LED Range: 98 ft (30 m)*3
• IR Wavelength: 850 nm |
| VIDEO |
| Max. Resolution |
1920x1080 |
| Main Stream |
• Frame Rate:
50Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
1920x1080, 1280x960, 1280x720
• Note:
If the image rotation is set to 90°, the frame rate only supports up to 20fps. |
| Sub-Stream |
• Frame Rate:
50Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz:1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
848x480,704x576, 640x480, 640x360,352x288, 320x240
• Note:
If the image rotation is set to 90°, the frame rate only supports up to 20fps. |
| Bit Rate Control |
CBR, VBR |
| Video Compression |
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264 |
| H.264 Type |
High Profile |
| H.264+ |
Main Stream Supported |
| H.265 Type |
Main Profile |
| H.265+ |
Main Stream Supported |
| Video Bit Rate |
• Main Stream: 256 Kbps to 4 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps |
| Image |
| Image Settings |
• Mirror
• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure
• WDR
• White Balance
• Prevent Overexposure to Infrared Light
• HLC Adjustable by Client Software |
| Image Enhancement |
BLC/3D DNR/HLC/Smart IR |
| Wide Dynamic Range |
DWDR |
| SNR |
≥ 52 dB |
| Image Parameters Switch |
Yes |
| Privacy Mask |
Up to 4 Masks |
| ROI |
1 Region |
| OSD Setting |
Yes |
| AUDIO |
| Audio Communication |
N/A |
| Audio Input |
Yes |
| Audio Output |
N/A |
| Audio Compression |
Yes |
| Audio Sampling Rate |
8 KHz |
| Environment Noise Filtering |
Yes |
| Audio Bit Rate |
64 Kbps(G.711 alaw) |
| NETWORK |
| Protocol |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| ONVIF |
Yes |
| API |
Open Network Video Interface (Profile S/T) |
| Simultaneous Live View |
3 Main Streams & 3 Sub-Streams |
| Client |
VIGI APP, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool |
| Web Browser |
• Google Chrome® 57 and above
• Firefox® 52 and above
• Safari® 11 and above
• Microsoft® Edge 91 and above |
| Cloud |
Yes |
| Security |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| ALARM AND EVENT MANAGEMENT |
| Smart Event |
• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• People Detection
• Vehicle Detection |
| Basic Event |
• Motion detection(Enhanced with Human & Vehicle Classification for more accurate alerts)
• Camera Tampering
• Exception (Illegal Login) |
| Alarm Linkage |
• Upload to FTP server
• Push Notifications
• Send to Alarm Server
• Email Alarm |
| INTERFACES |
| Network Interface |
1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm |
N/A |
| Reset Button |
N/A |
| Power |
DC Power Port |
| On-board Storage |
N/A |
| Built-in Microphone |
Yes; Records Anything Going on within a 15 ft (4.6 m) Radius of the Camera |
| Built-in Speaker |
N/A |
| Audio |
N/A |
| GENERAL |
| Operating Temperature |
-30 °C to 60 °C |
| Storage Temperature |
-40 °C to 60 °C |
| Operating Humidity |
95% or Less (Non-Condensing) |
| Storage Humidity |
95% or Less (Non-Condensing) |
| Package Content |
• VIGI Network Camera
• Quick Start Guide
• Waterproof Cable Attachments
• Mounting Accessories |
| Material |
Metal |
| Net Weight |
0.5 Kg |
| Power Supply |
• 12V DC ± 5%, Max. 6.3 W, 5.5 mm Coaxial Power Plug
• PoE: 802.3af/at, class 0, Max. 6.7 W |
| Protection |
IP67 Waterproof, IK10 Vandal Proof |
| Product Dimensions (L x W x H) |
Ø4.5 × 3.4 in (Ø113.5 × 85.7mm) |
| Certifications |
CE, NTRA, KC, FCC, VCCI, BSMI, ONVIF, IP67, IK10 |
