Panel Type |
|
IPS |
| |
Backlight |
|
Wide-Gamut LED |
| |
Panel Size |
|
31.1" / 78.9 cm |
| |
Native Resolution |
|
4096 x 2160 (17:9 aspect ratio) |
| |
Active Display Size (H × V) |
|
698.0 x 368.1 mm |
| |
Pixel Pitch |
|
0.170 x 0.170 mm |
| |
Pixel Density |
|
149ppi |
| |
Display Colors |
|
SDI, DisplayPort, HDMI: 1.07 billion from 24-bit palette |
| |
Viewing Angles (H, V) |
|
178°, 178° |
| |
Brightness (Typical) |
|
1000 cd/m2 (maximum) |
| |
Contrast Ratio (Typical) |
|
1,000,000:1 |
| |
Response Time (Typical) |
|
10 ms (Gray-to-gray) |
| |
Wide Gamut Coverage (typical) |
|
DCI-P3: 99% |
| |
Video Input Terminals |
|
BNC (12G/6G/3G/HD-SDI), BNC (3G/HD-SDI) x 3, DisplayPort (HDCP 1.3), HDMI (Deep Color, HDCP 2.2 / 1.4) |
| |
Video output Terminals |
|
BNC (12G/6G/3G/HD-SDI, through-out (active)), BNC (3G/HD-SDI, through-out (active)) x 3 |
| |
Digital Scanning Frequency (H, V) |
|
DisplayPort: 25 - 137 kHz, 23 - 61 Hz
HDMI: 15 - 136 kHz, 23 - 61 Hz |
| |
USB |
|
Upstream: USB 3.1 Gen 1: Type-B
Downstream: USB 3.1 Gen 1 Type-A x 3
(Battery Charging 10.5 W max. x1) |
| |
Power Requirements |
|
AC 100 - 240 V, 50 / 60 Hz |
| |
Power Consumption |
|
463 W |
| |
Typical Power Consumption |
|
282 W |
| |
Built-in Calibration Sensor |
|
Yes |
| |
Brightness Stabilization |
|
Yes |
| |
Digital Uniformity Equalizer |
|
Yes |
| |
Power Save Mode |
|
1.2 W or less |
| |
Standby Mode |
|
0.7 W or less |
| |
Preset Modes |
|
BT.2020, BT.709, DCI, PQ_BT.2100, PQ_BT.709, PQ_DCI, HLG_BT.2100, Calibration, Sync Signal |
| |
HDR Gamma |
|
HLG, PQ curve |
| |
OSD Languages |
|
English, German, French, Spanish, Italian, Swedish, Simplified Chinese, Traditional Chinese, Japanese |
| |
Others |
|
Color Adjustment, PQ Option, SelfCalibration, Input Color Format, YUV Color Matrix, Input Range, I/P Conversion, Black Level Lift, Deinterlacing, Time Code Settings, Interlace / PsF, Picture Expansion, Zoom, BT.709 Gamut warning, Luminance Warning, Co-View, Blue Only, Marker, Power Save, Off Timer, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock |
| |
Dimensions (Landscape, W x H x D) |
|
757 x 488 x 208 mm |
| |
Net Weight |
|
26.5 kg |
| |
Dimensions
(Landscape with wood,W x H x D) |
|
778 x 498.5 x 327 mm |
| |
Operating Temperature |
|
0 - 30 °C |
| |
Operating Humidity |
|
20 - 80 % |
| |
Certifications & Standards |
|
CB, CE, TUV/GS, cTUVus, FCC-A, CAN ICES-3 (A), TUV/S, PSE, VCCI-A, RCM, EAC, RoHS, WEEE, TUV/Ergonomics |
| |
Supplied Accessories |
|
AC power cord, signal cables (DisplayPort - DisplayPort, HDMI - HDMI), USB cable, setup guide, adjustment certificate, ScreenCleaner, monitor hood, warranty card, Clamp for HDMI |
| |
Warranty |
|
Five Years |
