產品介紹
7.2 Gbps 雙頻 WiFi 7: 讓您的裝置全速運轉,暢享流暢的 4K/8K 串流媒體播放、沉浸式 AR/VR 遊戲和極速下載。
多重連接模式 (MLO):透過多個頻段同時與 Wi-Fi 7 用戶端傳輸數據,以提高吞吐量、降低延遲並增強各種網絡行為的可靠性。 5
10G 和 2.5G 有線連接: 1 個 10 Gbps WAN/LAN 連接埠、1 個 2.5 Gbps WAN/LAN 連接埠和 3 個 1 Gbps LAN 連接埠提供高速資料傳輸。
兩種安裝方式: 無論是放在桌面上,還是掛在牆上,您都可以隨意放置路由器,以節省家中的空間。
兼容 EasyMesh: 可與 EasyMesh 路由器和信號擴展器配合使用,建立無縫的全屋 Mesh WiFi 網絡,防止在不同信號間切換時出現斷線和延遲。 7
設定和使用都很簡單: 有了 Tether app,網絡管理從未如此簡單。
TP-Link HomeShield: 增強型安全防護,抵禦最新網絡威脅。 6
相容性強: 支援所有 Wi-Fi 版本和裝置以及所有網絡服務供應商。 8
產品規格
| Wi-Fi 速度 |
BE7200
• 5 GHz: 5765 Mbps (802.11be)
• 2.4 GHz: 1376 Mbps (802.11be) |
| Wi-Fi 範圍 |
3 Bedroom Houses
Internal Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range |
| Wi-Fi 容量 |
High
Dual-Band
Allocate devices to different bands for optimal performance
MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
4 Streams
Connect your devices to more bandwidth |
| 進階功能 |
• Multi-Link Operation (MLO)
• 4K-QAM
• Multi-RUs
• EasyMesh-Compatible
• Works with Alexa and Google Assistant
• IoT Network |
| 無線模式 |
• Router Mode
• Access Point Mode |
|
安全性
|
| 網路安全性 |
• SPI Firewall
• Access Control
• IP & MAC Binding
• Application Layer Gateway
• HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner |
| 訪客網路 |
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network |
| VPN 伺服器 |
• OpenVPN Server
• PPTP VPN Server
• L2TP VPN Server
• WireGuard VPN Server |
| VPN 用戶端 |
• Open VPN Client
• PPTP VPN Client
• L2TP VPN Client
• WireGuard VPN Client |
| Wi-Fi 加密 |
• WPA
• WPA2
• WPA3
• WPA/WPA2-Enterprise (802.1x) |
|
硬體規格
|
| 網路孔 |
• 1× 10 Gbps WAN/LAN
• 1× 2.5 Gbps WAN/LAN
• 3× 1 Gbps LAN |
| 支援 USB |
1× USB 3.0
• Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32
• Supported Functions:
FTP Server
Media Server
Samba Server |
| 按鈕 |
• On/Off Button
• Wi-Fi/LED Button
• WPS Button
• Reset Button |
| 電源 |
12 V ⎓ 2.5 A |
|
軟體
|
| 協定 |
• IPv4
• IPv6 |
| 服務工具 |
HomeShield
Learn More> |
| EasyMesh |
Compatible with EasyMesh |
| 家長監護 |
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports |
| WAN 類型 |
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP |
| 服務品質 |
QoS by Device |
| 雲端服務 |
• Auto Firmware Upgrade
• TP-Link ID
• DDNS |
| NAT 轉發 |
• Port Forwarding
• Port Triggering
• DMZ
• UPnP |
| IPTV |
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN |
| DHCP |
• Address Reservation
• DHCP Client List
• Server |
| DDNS |
• TP-Link
• NO-IP
• DynDNS |
| 管理 |
• Tether App
• Webpage |
|
其他
|
| 預設啟用的網路服務 |
Web Server
Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
DNS
DNS
• Port: 53 Protocol: TCP & UDP
DHCP Server
IP address assignment (DHCP)
• Port: 67 Protocol: UDP
App management
Manage and configure device through app
• Port: 20001 Protocol: TCP
• Port: 30001 Protocol: TCP
• Port: 20002 Protocol: UDP |
| 系統需求 |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access) |
| 認證 |
CE, FCC, RoHS |
| 環境 |
• Operating Temperature: 0℃~40℃ (32℉ ~104℉)
• Operating Humidity: 10%~90% non-condensing |
