產品規格
Compatibility and Clearances
Motherboard Support
up to E-ATX (285 mm wide)
Fan Support
Top:
3x 120 mm | 3x 140 mm
Side:
3x 120 mm | 3x 140 mm (included)
Rear:
2x 120 mm (included)
Radiator Support
Top:
240 / 280 / 360 / 420 mm
Side:
240 / 280 / 360 / 420 mm
CPU Cooler
up to 171 mm
PSU
ATX up to 318 mm (200 mm with HDD Cage)
GPU
up to 482 mm (337 mm with Side Radiator)
Front I/O
USB-C (USB 3.2 Gen2x1 - 10 Gbps)
2x USB-A (USB 3.2 Gen1x1 - 5 Gbps)
3.5 mm Jack (Line-In/Out)
Power Button
Warranty
6 Years
Operating Ambient Temperature
0–40 °C
Net Weight
15.4 kg
Volume
64 l
Dimensions
529 (L) x 231 (W) x 529 (H) mm
Drive Bays
Behind the Mainboard Tray: 3× 2,5"
HDD Cage: 2x 3,5" or 2,5" + 1x 2,5"
PCI Slots
7
Cable Management Space
35 mm
Dust Filters
Top, Right Side
PSU RGB Stripe Specifications
LEDs
24 × A-RGB Gen 2 LEDs
Current | Voltage
0.89 A | 5 V DC
Connector
3-Pin A-RGB Plug + Socket
Fan Specification
2x P12 Pro A-RGB (pre-installed at rear)
Speed
600–3000 rpm
Air Flow
77 cfm | 131 m³/h
Static Pressure
6.9 mmH2O
Bearing
Fluid Dynamic Bearing
Current | Voltage
0.33 A | 12 V DC
Connector
4-Pin Fan Plug + Socket
RGB Specifications
LEDs
12x A-RGB Gen 2 LEDs
Current | Voltage
0.40 A | 5 V DC
Connector
3-Pin A-RGB Plug + Socket
3x P14 Pro Reverse A-RGB (pre-installed at side)
Speed
400–2650 rpm
Airflow
98 cfm | 166.5 m³/h
Static Pressure
5.1 mmH2O
Bearing
Fluid Dynamic Bearing
Current | Voltage
0.40 A | 12 V DC
Connector
4-Pin Fan Plug + Socket
RGB Specifications
LEDs
12 x A-RGB Gen 2 LED
Current | Voltage
0.40 A | 5 V DC
Connector
3-Pin A-RGB Plug + Socket
Vertical GPU Mounting Kit Specification
Dimensions
196 (L) x 153 (W) x 140 (H) mm
Supported Graphics Cards
Up to 482 mm Length and 3-Slot Mounting
Compatibility
PCIe 4.0 and Backward Compatible
Riser Cable
160 mm, PCIe 4.0 x16
PCI Slots Required
7
保用/保養條款
ARCTIC 產品保用資訊
保用期
除非特別標明,否則ARCTIC產品一律享有6年保用。
保用申請流程
- 由購買日起計,憑2000Fun收據及完整包裝及盒面保用貼紙,保用期及注意事項如上。
- 如購買後7日内產品出現質量問題,可交回2000Fun處理(不包括人為損壞);第8日開始由客戶自行向 ToppersTech 提出。
ToppersTech - 拓力科技
- 地址/Address :香港 九龍 長沙灣道266-268號 昌發商業大廈 405B
- Room 405b, 4/F, Chong Fat Commercial Building, 266-268 Cheung Sha Wan Road, Sham Shui Po, Kowloon
- 辦工時間 : 13:00 - 21:00 (逢星期三放假)
- 銷售/Sales : [email protected]
- 電話/Tel : (852) 5130 3149
