產品特色
- AXE5400 Tri-Band – AXE5400 Tri-Band Wi-Fi delivers Wi-Fi speeds up to 5400 Mbps.
- Cutting-Edge Processing – Armed with a 1.7 GHz Quad-Core CPU.
- SuperSpeed USB 3.0 – Up to 10× faster transfer speeds than USB 2.0.
- Wi-Fi 6E Unleashed – The brand new 6 GHz band brings more bandwidth, faster speeds, and near-zero latency.
- HomeShield – Customize your home network with enhanced security and control.
- OneMesh™ – Creates a Mesh network by connecting to a TP-Link OneMesh Extender for seamless whole-home coverage.
- Connect More Devices—OFDMA technology increases capacity by 4 times to enable simultaneous transmission to more devices.
- Ultra-Low Latency—Enables more responsive gaming and video chatting.
- Compatible with Alexa—Control your router via voice commands and make your life smarter and easier with Amazon Alexa.
產品內容
Wi-Fi 6E — Beyond the Boundaries of Wi-Fi 6
Wi-Fi 6E means Wi-Fi 6 extended to the 6 GHz band, bringing more bandwidth, faster speeds, and lower latency. Access to the 6 GHz frequency means high-bandwidth applications like AR/VR, 8K streaming run without buffering, drastically improving Wi-Fi performance. Wi-Fi 6E is one of the most advanced technologies nowadays. Even though Wi-Fi 6 gives you an ultra-fast experience,Wi-Fi 6E will be better than that. Now it’s time to upgrade your home Wi-Fi to Wi-Fi 6E!

Extraordinary Speed ,Exclusive Experience
AXE75 provides industry-leading speeds of up to 2402 Mbps on a clean 6GHz band, 2402 Mbps on a 5GHz band, and 574 Mbps on a 2.4GHz. 5400Mbps Wi-Fi enables most of your devices to run at full speed, and there will be no latency in games,no freeze in video chatting,no buffering in 4K/8K streaming. With the upgraded 6G speed, you can fully enjoy the extraordinary speed without any lag.


產品規格
| 標準 |
IEEE 802.11ax 6 GHz,
IEEE 802.11ax/ac/n/a 5 GHz,
IEEE 802.11ax/n/b/g 2.4 GHz |
| Wi-Fi 速度 |
AXE5400
6 GHz: 2402 Mbps (802.11ax)
5 GHz: 2402 Mbps (802.11ax)
2.4 GHz: 574 Mbps (802.11ax) |
| Wi-Fi 範圍 |
2-3 Bedroom Houses
6× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
High-Power FEM
Improves transmission power to strengthen signal coverage |
| Wi-Fi 容量 |
Very High
Tri-Band
Allocate devices to different bands for optimal performance
OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
6 Streams
Connect your devices to more bandwidth |
| 運作模式 |
Router Mode
Access Point Mode |
| 硬體規格 |
| 處理器 |
1.7 GHz Quad-Core CPU |
| 網路孔 |
1× Gigabit WAN Port
4× Gigabit LAN Ports |
| 支援 USB |
1× USB 3.0 Port
Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32
Supported Functions:
Apple Time Machine
FTP Server
Media Server
Samba Server |
| 按鈕 |
Wi-Fi On/Off Button
Power On/Off Button
LED On/Off Button
WPS Button
Reset Button |
| 電源 |
12 V ⎓ 2.5 A |
| 安全性 |
| Wi-Fi 加密 |
WPA,
WPA2,
WPA3,
WPA/WPA2-Enterprise (802.1x) |
| 網路安全性 |
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner |
| 訪客網路 |
1× 6 GHz Guest Network,
1× 5 GHz Guest Network,
1× 2.4 GHz Guest Network |
| VPN 伺服器 |
OpenVPN Server
PPTP VPN Server
L2TP VPN Server |
| VPN 客戶端 |
Open VPN Client
PPTP VPN Client
L2TP VPN Client |
| 軟體 |
| 協定 |
IPv4
IPv6 |
| 服務工具 |
HomeShield
Learn More> |
| OneMesh™ |
OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Learn More>
All OneMesh Products> |
| 家長監護 |
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports |
| WAN 類型 |
Dynamic IP
Static IP
PPPoE
PPTP
L2TP |
| 服務品質 |
QoS by Device |
| 雲端服務 |
Auto Firmware Upgrade
TP-Link ID
DDNS |
| NAT 轉發 |
Port Forwarding
Port Triggering
DMZ
UPnP
Virtual Server |
| IPTV |
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN |
| DHCP |
Address Reservation
DHCP Client List
Server |
| DDNS |
TP-Link
NO-IP
DynDNS |
| 管理 |
Tether App
Webpage |
| 實體 |
| 體積 (W×D×H) |
10.7 × 5.8 × 1.9 in
(272.5 × 147.2 × 49.2 mm) |
| 包裝內容 |
Wi-Fi Router Archer AXE75
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide |
| 其他 |
| 系統需求 |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled
browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access) |
| 認證 |
FCC, RoHS |
| 環境 |
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing |
| 測試數據 |
| Wi-Fi 傳輸功率 |
FCC: ≤29dBm (2.4 GHz), ≤28dBm (5 GHz), ≤22dBm (6 GHz)
CE: ≤17dBm (2.4 GHz), ≤27dBm (5 GHz), ≤20dBm (6 GHz) |
| Wi-Fi 接收靈敏度 |
2.4 GHz:
11ax HE20 MCS0:-95dBm, 11ax HE20 MCS11:-64dBm
11ax HE40 MCS0:-92dBm, 11ax HE40 MCS11:-62dBm
5 GHz:
11ax HE20 MCS0:-94dBm, 11ax HE20 MCS11:-63dBm
11ax HE40 MCS0:-91dBm, 11ax HE40 MCS11:-60dBm
11ax HE80 MCS0:-88dBm, 11ax HE80 MCS11:-57dBm
11ax HE160 MCS0:-85dBm, 11ax HE160 MCS11:-54dBm
6 GHz:
11ax HE20 MCS0:-93dBm, 11ax HE20 MCS11:-62dBm
11ax HE40 MCS0:-90dBm, 11ax HE40 MCS11:-59dBm
11ax HE80 MCS0:-87dBm, 11ax HE80 MCS11:-56dBm
11ax HE160 MCS0:-84dBm, 11ax HE160 MCS11:-53dBm |
